| * Conforms to IEEE802.3, 802.3u and 802.3x Ethernet Standards |
| * 5 ports auto-negotiation 10/100Mbps Ethernet RJ-45 ports |
| * Automatic MDI/MDIX crossover for each 10Base-T/100Base-TX
port |
| * Backpressure for Half-duplex mode and Flow control for
Full-duplex mode |
| * Store-and-forward switching architecture |
| * 1K entry MAC address table and automatic address learning
|
| * Performs non-blocking full wire speed |
| * LED-indicator for Power, LK/ACT |
|
 |
 |
 |
| * Standard |
IEEE 802.3 10BASE-T Ethernet |
| IEEE 802.3u 100BASE-TX Fast Ethernet |
| IEEE 802.3x Flow Control and Back-Pressure |
| ANSI/IEEE standard 802.3 N-Way auto-negotiation |
| * Protocol |
CSMA/CD |
| * Connector |
5s 10/100TX ports RJ-45 |
| * Switch Architecture |
Store and Forward Switch Technology |
| * Network Cables |
Cat.3,4,5,6,7 UTP/STP |
| * Filter/Forward Rate |
10 BASE-T, 880pps (packet/sec.) |
| 100 BASE-TX, 148,800pps(packet/sec.) |
| * Mac Address |
1K MAC with Auto Learning |
| * Led |
Per Port LK/ACT |
| Per Unit-Power |
| * Power |
외장형 어댑터 |
| * Operate TemPerature |
Operating 0~45℃ |
| * Storage |
-20~70℃ |
| * Humidity |
10% to 90%(non-condensing) |
| * Size |
132 X 75 X 24 (mm) |
|
 |
 |
